Introduction

In my previous blog post AWS With Federated Identity Using OpenID Connector, I explained how I used OpenID with AWS IAM Role.

In this new blog post, I describe how I linked the previously created IAM Role with Kubernetes service account.

What is a Kubernetes Service Account?

A Kubernetes Service Account is an entity in a Kubernetes cluster which provides a distinct identity.

To be able to interact with the cloud environment, you need to link the Kubernetes service account to some cloud role resource, e.g. AWS IAM Role.

Use Case

I needed to do a Kubernetes rolling update to provide a zero downtime update for the Kubernetes pods to use a new Docker image. The use case is this. We have a CI/CD pipeline (Github Actions) that does the following steps with each commit:

  • Run tests and build the app.
  • Create a new Docker image.
  • Push the Docker image to AWS ECR.
  • Do a Kubernetes rolling update for the new image.

EKS allows kubernetes API calls for the IAM User that created the EKS resource. For another IAM User or Role, use a Kubernetes service account and link it with an IAM Role.

Create the service account:

---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: github-service-account
  namespace: demo1

Then create a Kubernetes role:

---
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  name: github-role
  namespace: demo1
rules:
  - apiGroups:
...

And a role binding between the service account and the role:

---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: github-rolebinding
  namespace: demo1
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: Role
  name: github-role
subjects:
- namespace: demo1
  kind: ServiceAccount
  name: github-service-account

Apply these entities to your kubernetes cluster.

Finally you need to link the service account with the AWS IAM role that your CI/CD uses, example:

eksctl create iamidentitymapping --cluster $EKS_CLUSTER_NAME --arn $AWS_GITHUB_IAM_ROLE_ARN --username github-service-account --group system:masters

To make things easier for this demo, I used group system:masters - you might want to create a more restricted group for deployments in a real production environment.

Now you are able to do the rolling update in your CI/CD pipeline:

kubectl rollout restart deployment deployment-demo1 -n demo1

Conclusions

In this blog post I described how you can link a Kubernetes service account with an AWS IAM Role, so that you are able to use the service account to do e.g. rolling updates in your Kubernetes deployments.
